User’s Manual of IXT-900 PoE series
16
1.4 Product Features
Physical Port
 One 10G/5G/2.5G/1G/100BASE-T RJ45 interface with auto MDI/MDI-X function
 One (Two) 10G/2.5G/1G/100BASE-X SFP+ interface
 Supports IEEE 802.3bt PoE++ standard
IEEE 802.3bt Power over Ethernet
 Compliant with IEEE 802.3bt Type-4 PoE++ standard
 Backward compatible with IEEE 802.3af/at PD device
 The RJ45 port on the IXT-900 PoE series delivers a maximum power output of 95 watts, which is also the maximum
PoE budget the device can provide.
 Detects powered devices (PD) automatically.
 Power feeding up to 100m
 PoE management features
- PoE admin-mode control
- PoE port power limit
- PD classification detection
 Intelligent PoE features
- Temperature threshold setting
- PoE usage threshold setting
- PD alive check
- PoE schedule
Layer 2 Features
 Storm Control support
− Broadcast / Multicast / Unknown Unicast
 Supports VLAN
− IEEE 802.1Q tagged VLAN.
− Supports provider bridging (VLAN Q-in-Q, IEEE 802.1ad)
− Up to 256 VLAN groups, out of 4096 VLAN IDs
 Supports ITU-T G.8032 ERPS ring with recovery time less than 500ms (software-based)
 Link Layer Discovery Protocol (LLDP)
 16K MAC address table with auto-aging
 Jumbo Frame support up to 9K in size.
Quality of Service
 Ingress Shaper and Egress Rate Limit per port bandwidth control
 8 priority queues on all converter ports
 Strict priority and Weighted Round Robin (WRR) CoS policies
 Traffic classification
− IEEE 802.1p CoS
− IP TOS / DSCP / IP Precedence
− IP TCP/UDP port number
− Typical network application
