User’s Manual of IXT-900 PoE series
145
4.4.3 QoS Basic Mode
4.4.3.1 Global Settings
The Basic Mode Global Settings and QoS Information screen in Figure 4-4-13 & Figure 4-4-14 appear.
Figure 4-4-13 Basic Mode Global Settings Page Screenshot
The page includes the following fields:
Object
Description
 Trust Mode
Set the QoS mode.
Buttons
: Click to apply changes.
 QoS Information
Figure 4-4-14 QoS Information Page Screenshot
The page includes the following fields:
Object
Description
 Trust Mode
Display the current QoS mode.
