User’s Manual of IXT-900 PoE series
48
4.2.1.2 IP Configurations
The IP Configuration includes the IP Address, Subnet Mask and Gateway. The configuration column is used to view or change
the IP configuration. Fill out the IP Address, Subnet Mask and Gateway for the device. The screens are shown in Figure 4-2-2
and Figure 4-2-3.
Figure 4-2-2 IP Address Setting Screenshot
he page includes the following fields:
Object
Description
 Mode
Indicates the IP address mode operation. Possible modes are:
Static: Enable NTP mode operation.
When enabling NTP mode operation, the agent forwards and transfers
NTP messages between the clients and the server when they are not on
the same subnet domain.
DHCP: Enable DHCP client mode operation.
Enable the DHCP client by checking this box. If DHCP fails and the
configured IP address is zero, DHCP will retry. If DHCP fails and the
configured IP address is non-zero, DHCP will stop and the configured IP
settings will be used. The DHCP client will announce the configured
System Name as hostname to provide DNS lookup.
 IP Address
Provide the IP address of this media converter in dotted decimal notation.
 Subnet Mask
Provide the subnet mask of this media converter in dotted decimal notation.
 Gateway
Provide the IP address of the router in dotted decimal notation.
 DNS Server 1/2
Provide the IP address of the DNS Server in dotted decimal notation.
Buttons
: Click to apply changes.
