2.2 Installing the Industrial Media Converter
This section describes how to install your Industrial 10G Managed PoE Media Converter and make connections to the
Industrial Media Converter. Please read the following topics and perform the procedures in the order being presented. To
install your Industrial 10G Managed PoE Media Converter on a desktop or shelf, simply complete the following steps.
In this paragraph, we will describe how to install the Industrial 10G Managed PoE Media Converter and the installation points
attended to it.
2.2.1 Installation Steps
1. Unpack the Industrial 10G Managed PoE Media Converter
2. If users want to wall-mount the Industrial 10G Managed PoE Media Converter, please refer to the Wall Mount Plate
Mounting section for wall-mount plate installation.
3. Hangs the Industrial 10G Managed PoE Media Converter on the wall.
4. Power on the Industrial 10G Managed PoE Media Converter. Please refer to the Wiring the Power Inputs section to get
the information about how to wire the power. The power LED on the Industrial 10G Managed PoE Media Converter will
light up. Please refer to the LED Indicators section for indication of LED lights.
5. Prepare the twisted-pair, straight-through Category 5 cable for Ethernet connection.
6. Insert one side of RJ45 cable (category 5) into the 10G Media Converter’s Ethernet port (RJ45 port) while the other
side to the network device’s Ethernet port (RJ45 port), e.g., Media converter PC or Server. The UTP port (RJ45) LED on the
Industrial 10G Managed PoE Media Converter will light up when the cable is connected with the network device. Please
refer to the LED Indicators section for LED light indication.
Make sure that the connected network devices support MDI/MDI-X. If it does not support,
use the crossover Category 5 cable.
7. When all connections are set and all LED lights show normal, the installation is completed.
2.2.2 Wall Mount Plate Mounting
To install the Industrial 10G Managed PoE Media Converter on the wall, please follow the instructions below.
Step 1: Place the wall-mount plate on the rear panel of the Industrial 10G Managed PoE Media Converter.
Step 2: Use the screwdriver to screw the wall mount plate on the Industrial 10G Managed PoE Media Converter.
Step 3: Use the hook holes at the corners of the wall mount plate to hang the Industrial 10G Managed PoE Media Converter
on the wall.
Step 4: To remove the wall mount plate, reverse the steps above.
