4.4.5.2 Port Setting
Storm control for the switch is configured on this page. There are three types of storm rate control:
 Broadcast storm rate control
 Unknown Multicast storm rate control
 Unknown Unicast storm rate control
The configuration indicates the permitted packet rate for unknown unicast, unknown multicast, or broadcast traffic across the
switch. The Storm Control Configuration screens in Figure 4-4-25 & Figure 4-4-26 appear.
Figure 4-4-25 Storm Control Setting Page Screenshot
The page includes the following fields:
Object
Description
 Port
Select port for this drop down list.
 Port State
Enable or disable the storm control status for the given storm type.
 Action
Configures the action performed when storm control is over rate on a port. Valid
values are Shutdown or Drop.
 Type Enable
The settings in a particular row apply to the frame type listed here:
 Broadcast
 Unknown Multicast
 Unknown Unicast
 Rate (kbps/pps)
Configure the rate for the storm control. The default value is "10,000".
Buttons
: Click to apply changes
