Planet IXT-900-1X1UP - RMON Event Log

User’s Manual of IXT-900 PoE series
80
Figure 4-2-41: RMON Event Status Screenshot
The page includes the following fields:
Object
Description
 Index
Display the current event index
 Event Type
Display the current event type
 Community
Display the current community for SNMP trap
 Description
Display the current event description
 Last Sent Time
Display the current last sent time
 Owner
Display the current event owner
 Action
Click to delete RMON event entry
4.2.5.3 RMON Event Log
This page provides an overview of RMON Event Log. The RMON Event Log Table screen in Figure 4-2-42 appears.
Figure 4-2-42: RMON Event Log Table Screenshot
The page includes the following fields:
Object
Description
 Select Index
Select index from this drop-down list
 Index
Indicates the index of the log entry
 Log Time
Indicates Event log time
 Description
Indicates the Event description
