4.4.4.2 Egress Bandwidth Control
This page provides to select the egress bandwidth preamble. The Egress Bandwidth Control Setting and Status screens in
Figure 4-4-19 & Figure 4-4-20 appear.
Figure 4-4-19 Egress Bandwidth Control Settings Page Screenshot
The page includes the following fields:
Object
Description
 Port
Select port number for this drop down list.
 State
Enable or disable the port rate policer. The default value is "Disabled".
 Rate (Kbps)
Configure the rate for the port policer. The default value is "unlimited". Valid
values are in the range 16 to 1000000.
Buttons
: Click to apply changes.
Figure 4-4-20 Egress Bandwidth Control Status Page Screenshot
The page includes the following fields:
Object
Description
 Port
The switch port number of the logical port.
 Egress Rate Limit (Kbps)
Display the current egress rate limit.
