User’s Manual of IXT-900 PoE series
18
1.5 Product Specifications
Model
IXT-900-1X1UP
IXT-900-2X1UP
Hardware Specifications
Copper Interface
1 x 10G/5G/2.5G/1G/100BASE-T RJ45 interface with auto MDI/MDI-X function supporting
IEEE 802.3bt PoE++ standard
Fiber Interface
1x 10G/2.5G/1G/100BASE-X SFP+ interface
2x 10G/2.5G/1G/100BASE-X SFP+ interface
Reset Button
< 5 sec.: System reboot
> 5 sec.: Factory default
Connector
Removable 6-pin terminal block for power input
Pin 1/2 for Power 1, Pin 3/4 for Alarm, Pin 5/6 for Power 2
Alarm
One relay output for power failure. Alarm relay current carry ability: 1A @ 24VDC
Enclosure
IP40 metal case
ESD Protection
4KVDC Contact / 8KVDC Air
Installation
Wall-mount and DIN-rail kit installation
Dimensions (W x D x H)
50 x 87 x 135mm
Weight
659g
720g
Power Requirement
12~54V DC
Power Consumption
12VDC: 5.86W/20 BTU (No Loading)
70.8W/241.6 BTU (Full Loading)
54VDC: 6.3W/21.4 BTU (No Loading)
102.7W/350.43 BTU (Full Loading)
12VDC: 5.5W/18.8 BTU (No Loading)
71W/242.3 BTU (Full Loading)
54VDC: 6.2W/21.2 BTU (No Loading)
105W/358.3 BTU (Full Loading)
LED Indicator
System:
PWR 1/2, (Green)
Alarm (Red)
PoE:
802.3bt PoE-in-Use (Green)
802.3at PoE-in-Use (Amber)
Per 10GBASE-T RJ45 Port:
100/1G LINK/ACT (Green)
2.5G/5G LINK/ACT (Green)
10G LINK/ACT (Amber)
Per 10GBASE-X SFP+ Port:
100/1G LINK/ACT (Green)
2.5G LINK/ACT (Green)
10G LINK/ACT (Amber)
Transmission Specifications
Processing Scheme
Store and Forward
Fabric
40Gbps
60Gbps
Throughput
(packet per second)
29.76Mpps@64bytes
Address Table
16K entries, automatic source address learning and aging
Flow Control
Back pressure for half duplex
IEEE 802.3x pause frame for full duplex
Jumbo Frame
9K
Shared Buffer
12Mbits
Power Over Ethernet
PoE Standard
IEEE 802.3bt PoE++ Type-4 PSE
