4.3.1.4 Jumbo Frame
This page provides to select the maximum frame size allowed for the port. The Jumbo Frame screen in Figure 4-3-10 and
Figure 4-3-11 appear.
Figure 4-3-10 Jumbo Frame Setting Screenshot
The page includes the following fields:
Object
Description
 Jumbo Frame (Bytes)
Enter the maximum frame size allowed for the port, including FCS. The
allowed range is from 64 bytes to 9216 bytes.
Buttons
: Click to apply changes.
Figure 4-3-11 Jumbo Frame Information Screenshot
The page includes the following fields:
Object
Description
 Jumbo
Display the current maximum frame size
