User’s Manual of IXT-900 PoE series
92
4.3.1.2 Port Counters
This page provides an overview of traffic and trunk statistics for all ports. The Port Statistics screens in Figure 4-3-3, Figure
4-3-4, Figure 4-3-5 and Figure 4-3-6 appear.
Figure 4-3-3 Port MIB Counters Screenshot
The page includes the following fields:
Object
Description
 Port
Select port number from this drop-down list.
 Mode
Select port counters mode.
Option:
 All
 Interface
 Ether-link
 RMON
Figure 4-3-4 Interface Counters Screenshot
