User’s Manual of IXT-900 PoE series
166
RPL Configuration:
Object
Description
 RPL Role
It can be either RPL owner or RPL Neighbor.
 RPL Port
This allows to select the east port or west port as the RPL block.
 Clear
If the owner has to be changed, then the clear check box allows to clear the RPL
owner for that ERPS ring.
Instance Command:
Object
Description
 Command
Administrative command. A port can be administratively configured to be in either
manual switch or forced switch state.
 Port
Port selection - Port0 or Port1 of the protection Group on which the command is
applied.
ERPS state:
Object
Description
 Protection State
ERPS state according to State Transition Tables in G.8032.
 Port 0
OK: State of East port is ok
SF: State of East port is Signal Fail
 Port 1
OK: State of West port is ok
SF: State of West port is Signal Fail
 WTR Remaining
Remaining WTR timeout in milliseconds.
 RPL Un-blocked
APS is received on the working flow.
 Port 0 Block Status
Block status for Port 0 (Both traffic and R-APS block status). R-APS channel is
never blocked on sub-rings without virtual channel.
 Port 1 Block Status
Block status for Port 1 (Both traffic and R-APS block status). R-APS channel is
never blocked on sub-rings without virtual channel.
