power automation PA 8000 User Manual

Pin Description
Pin 1 +/- output channel 1
Pin 2 reference channel 1
Pin 3 +/- output channel 2
Pin 4 reference channel 2
Pin 5 +/- output channel 3
Pin 6 reference channel 3
Pin 7 +/- output channel 4
Pin 8 reference channel 4
Property Value Unit
Number of analog
output points
4
Output signal range
(max.)
+/- 10 V
Output current load
(max.)
+/- 15 mA
Output capacitive
load (max.)
350 pF
Bipolar zero error
(max.)
+/- 40 mV
Full scale error
(max.)
+/- 1 1 %
Channel to channel
mismatch (max.)
+/- 1 %
Linearity error
(max.)
+/- 2.44 mV
Resolution 305 μV
Conversion time
(max.)
10 μs
Output slew rate
(typ.)
0.4 V/us
Watchdog (max.) 64 ms
External connector 8 pole terminal block
Pin Assignment
Output Characteristics
PA 8000 PAMIO
PAMIO Components
12.01.2017 | 108

power automation PA 8000 Specifications

General

Brand	power automation
Model	PA 8000
Category	Control Unit
Language	English
