4.2.3 Mechanical assembly
The PAMIO boxes must always be mounted on the rail in such a
way that the power supply connector of the modules is on the top
side.
Snap the back of the PAMIO box onto the DIN rail by inserting the
top on the rail and then pressing simultaneously down and in at the
bottom of the box. Be sure to hold the box absolutely horizontally
when pressing down. Also make sure that a fastening screw of the
DIN rail is located right in the middle of the PAMIO box bracket.
Shift the boxes together. The box should slide on the DIN rail. If it
does not slide then slightly press the box down while moving the
box.
The total length of a PAMIO box rack is given by
the formula:
– Total length = N x 105.3 mm + 5 mm
– Total length = N x 4.16 inches + 0.20 inches
where N stands for the number of PAMIO boxes
Mounting Of The PAMIO Boxes
PA 8000 PAMIO
PAMIO Components
12.01.2017 | 35
