4.1.5 Bus termination
As with other fast bus systems, the PA Superbus requires a termi-
nation to avoid line reflections that could disturb the data transmis-
sion.
The last PAMIO box of a system rack must carry a bus termination
plug on its Superbus output connector. In the particular case of a
PAMIO of model 2ENC4A, there is no Superbus output connector
and the bus termination is integrated in the module (by the way, it
is not possible to use more than one such a module per system
rack!).
4.2 Mechanical Installation
4.2.1 Dimensions
4.2.1.1 PAMIO models 2416 / 4ENC4A / PWM
Property Value Unit
Dimensions 112 x 123 x 181.5 mm
4.4 x 4.84 x 7.15 inch
Weight of the back-
plane
0.66 kg
1.46 lb
Max. weight 1.36 kg
3.00 lb
The weight of a PAMIO box depends on the model
and the number of single modules mounted on the
backplane. The example here above gives the
weight of a box including two modules 4ENC4A.
Refer to the specific technical data of each single
module to determine the exact weight of your box.
Bus Termination
General
PA 8000 PAMIO
PAMIO Components
12.01.2017 | 30
