power automation PA 8000 - Design and Functions

Property Value Unit
Input voltage 24 V DC
Tolerance -15 / +12.5 %
Frequency 20.4 - 27.0 V DC
Max. current 0.5 A
4.6.2 Design and Functions
Fig. 61: PAMIO PWM overview
1 Power connector +24 V (X30)
2 Output byte
3 Protective grounding tab (X2)
4 Status LEDs output byte
5 Module status LEDs
Connection Values
Overview
PA 8000 PAMIO
PAMIO Components
