4.7.8 Status LEDs

Fig. 96: PAMIO 2ENC4A module status LEDs

6 Module status LEDs

The PAMIO 2ENC4A has six LEDs for diagnostic purposes.

1 Status

2 Access

3 Bustest

4 Monitor

5 Axis 1

6 Axis 2

For a detailed assignment of the LEDs' states see

Chapter 5.2.4

“PAMIO 2ENC4A LEDs” on page 126.

Overview

PA 8000 PAMIO

PAMIO Components
