4.4.2.3 Power Supply
Each of the output bytes on the PAMIO 2416 needs a separate
+24V DC power supply. This is done on the power supply con-
nector X30 (Fig. 36).
Fig. 36: PAMIO 2416 power connection
2 Power connection (X30)
Each module has a 5 pin connector (X30) with the following pin
assignment (Fig. 37):
Fig. 37: X30 – Power supply pins
Connection
PA 8000 PAMIO
PAMIO Components
12.01.2017 | 62
