For a detailed assignment of the LEDs' states see Ä Chapter 5.2.3
“PAMIO PWM LEDs” on page 124.
4.7 PAMIO 2ENC4A
The PAMIO module 2ENC4A has connections for:
n 2 analog axes (4 analog command outputs +/- 10 V DC / 16 bit)
n 4 incremental measurement systems)
n 2 supplementary analog inputs (+/-10V DC / 12 bit)
This special module has an integrated bus termi-
nation. Because of its internal bus termination,
there can be only one such PAMIO model in a
system rack, and it must be the last module of the
rack.
The status of the monitor is displayed via LEDs.
4.7.1 Technical Data
Property Value Unit
Weight 0.55 kg
1.21 lb
Property Value Unit
Input voltage 24 V DC
Tolerance -15 / +12.5 %
Frequency 20.4 - 27.0 V DC
Max. current 0.2 A
Connections Of The PAMIO
2ENC4A
General
Connection Values
PA 8000 PAMIO
PAMIO Components
12.01.2017 | 97
