4.4 PAMIO 2416
The PAMIO module 2416 has connections for:
n 24 digital inputs (3 bytes)
n 16 digital outputs (2 bytes)
All the signals are 24V DC.
Each output byte can be supplied separately. Each output can
drive up to 0.7A, each byte being limited to 4A maximum.
The status of the inputs, the outputs and the monitor is displayed
via LEDs.
4.4.1 Technical Data
Property Value Unit
Weight 0.29 kg
0.64 lb
Property Value Unit
Input voltage 24 V DC
Tolerance -15 / +12.5 %
Frequency 20.4 - 27.0 V DC
Max. current 0.1 A
Connections Of The PAMIO 2416
General
Connection Values
PA 8000 PAMIO
PAMIO Components
12.01.2017 | 52
