4.6.2.3 Power Supply

The output byte on the PAMIO PWM needs a separate +24V DC

power supply. This is done on the power supply connector X30

(Fig. 74).

Fig. 74: PAMIO PWM power connection

1 Power connection (X30)

Each module has a 5 pin connector (X30) with the following pin

assignment (Fig. 75):

Fig. 75: X30 – Power supply pins

Connection

PA 8000 PAMIO

PAMIO Components

12.01.2017 | 94
