Place M6 fixation screws every 105.3 mm (4.16 inches) (see
Fig. 10).
Fig. 10: M6 fixation
In this way the DIN rail fixation screws are placed right in the
middle of the PAMIO boxes (Fig. 11). So, optimum fixation is guar-
anteed and the user can install and/or remove PAMIO boxes
without any problem.
Fig. 11: DIN rail fixation
M6 Fixation
PA 8000 PAMIO
