LED state Module status
Off Default
On Bustest between control unit and the last PAMIO
module is active
LED state Module status
Off Error 1: The ambient temperature is above 60 °C
(140 °F) and all outputs are disabled by the
onboard logic
OR Error 2: The watchdog is re-triggered but the 24 V
output supply has been interrupted for more than
60 seconds. In this case the onboard logic switches
off the corresponding 24 V outputs.
Flashing Warning 1: The ambient temperature is above
55 °C (131 °F)
OR Warning 2: The watchdog is re-triggered but the 24
V output supply has been interrupted for more than
15 seconds
OR Warning 3: Outputs are overloaded
On The 24 V output supply is correct (Default)
AND There is no temperature error
LED "Bustest" (3)
LED "Monitor" (4)
PA 8000 PAMIO
Troubleshoong
12.01.2017 | 120
