LED state Module status
Quick flash The module is configured but the outputs are disa-
bled because the watchdog is not re-triggered
On The module is configured and the analog outputs
are enabled
LED state Module status
Off Default
On Access to this module
LED state Module status
Off Default
On Bustest between control unit and the last PAMIO
module is active
LED state Module status
Off Error 1: The ambient temperature is above 60 °C
(140 °F) and all outputs are disabled by the
onboard logic
Flashing Warning: The ambient temperature is above 55 °C
(131 °F)
On Default
LED state Module status
Off Axis is not connected
OR Axis is connected and an encoder wire break has
been detected
Flashing Axis is connected and a wrong sequence of signals
on track A and B has occurred
On Axis is connected and no wire break has been
detected
NOTICE!
A wrong sequence of axis signals is detected when
the A and B track of an incremental measuring
system shows an incorrect sequence of rising and
falling edges. This can occur in case of interfer-
ences on the signals.
LED "Access" (2)
LED "Bustest" (3)
LED "Monitor" (4)
LED "Axis 1" - LED "Axis 2" (5/6)
PA 8000 PAMIO
Troubleshoong
12.01.2017 | 127
