Property Value Unit
Number of relays 2
Max. switching
voltage
30 V DC
Max. switching cur-
rent
1 A
Typical switch on
time
4 ms
Typical switch off
time
3 ms
The first relay is called "Power OK" and switches when the fol-
lowing conditions are met:
n The power supply voltages are in operating range.
n The operating temperature is below +60 °C (+140 °F).
Logic Condition Result
+ 5 V OK Power OK relay
active
AND +15 V OK
AND -15 V OK
AND T < 60 °C (140 °F)
NOTICE!
Damage to the control unit!
Voltage faults and/or temperatures above the
allowed specification can cause damage to the
control unit.
Properly wire the "Power OK" relay to protect the
control unit from damaging voltages and tempera-
tures.
Technical Data
Relay "Power OK"
PA 8000 PAMIO
PAMIO Components
12.01.2017 | 82
