Back of TARGAS-1
External Air Filter
An air filter is included with each system and we recommend fitting it to the AIR IN port to keep dirt and
dust from entering the analyzer. See External Air Filter on page 140 for more information.
Power Switch
External
Power/Charger
socket
Probe port 1
External Power
LED Indicator
PLC Electrical
(Probe port 2)
Connection
PLC Gas Port
Gas Out
Gas In
USB Flash Drive USB Mini-B
Link Tube
Must be in place for
use with leaf cuvette
A. Auto-Zero (Molecular Sieve)
B. CO
2
Scrubber (Sofnolime)
C. H
2
O Scrubber( Drierite)
A
B
C
