PP Systems TARGAS-1 - CPY - Termination Settings (Step 3); CPY - Other Settings (Step 4)

TARGAS-1 Operation Manual V. 1.02 82 support@ppsystems.com
Right Arrow Button
Continues to CPY – Termination Settings menu (Step 3).
CPY – Termination Settings (Step 3)
The Termination Settings (DT, DC) as well as Delay are defined in this screen.
CPY – Termination Settings Menu
DT Button
Maximum time for which changes in the chamber CO
2
concentration are
monitored in a given session. Valid entries range between 10 - 300 seconds.
DC Button
Maximum negative change in CO
2
concentration (ppm) allowed in a given
session. If total change exceeds this value the session will end. Valid entries
are between 1 - 1,000 ppm.
Delay Button
The amount of time the instrument waits at the start of each session before it
starts calculating assimilation. Valid entries are between 5 – 150 seconds.
Stop Button
Stops the CPY process and returns to the Processes Menu.
Right Arrow Button
Continues to CPY – Other Settings Menu (Step 4).
CPY – Other Settings (Step 4)
The plot number is defined in this screen.
CPY – Other Settings Menu
Plot Number Button
Change/View plot number. Range: 0–1000.
