PP Systems TARGAS-1 - Graph Setting; Reset Zero Absorber

TARGAS-1 Operation Manual V. 1.02 57 support@ppsystems.com
Graph Setting
Max CO2 Setting
Radio Buttons
To set the Y-axis range for any Graphical Display Screen that displays CO
2
.
Back Button
Returns to the Graph Settings screen.
Reset Zero Absorber
Reset Zero Absorber
Yes Button
Reset the Zero Absorber capacity gauge to 100%. This should be set every time
the molecular sieve is changed in the Auto-Zero column to ensure reporting
accuracy.
No Button
Returns to the Settings 1 Menu without resetting the Zero Absorber capacity
gauge.
