TARGAS-1 Operation Manual V. 1.02 27 support@ppsystems.com
Schematic of TARGAS-1 Portable Photosynthesis System Air
Supply System
Air Supply
Intake Unit
Air in
no
C
nc
H
2
O IRGA
Pump
GAS IN
Zero CO2 H2O
GAS OUT
AN / Zero Valve
REF Valve
CO
2
IRGA
Molecular
Sieve
Filter
Filter
Filter
Filter
PLC AN IN
Gas Measuring System
Flow Sensor
no
C
nc
Air Control System
nc
C
no
AIR IN
PLC Air Out
REF OUT
H
2
O
Control
Filter
CO
2
Control
nc
C
no
CO
2
Absorber
H
2
O
Absorber
Smoothing
Volume
Pump
Flow Sensor
TARGAS-1 CO
2
/H
2
O Gas
Analyzer
PLC5 Leaf
Cuvette
Link to connect
REF OUT to GAS IN
Note
PLC AirOut and PLC An In are
both located within the white, dual
PLC port connector.
