TARGAS-1 Operation Manual V. 1.02 39 support@ppsystems.com
General Screen Info
New screens are displayed by the user selecting either the lower left or the lower right buttons. Generally
speaking, the left button brings you back to the previous screen and the right button to the next available
screen.
Measure Screen Info
Each screen contains common features.
1. There is a pulsing
♥ icon to confirm that the TARGAS-1 display is actively on. Press this icon to
return to normal 1 second display updates when the display has changed to extended mode with
5 second updates.
2. The percentage value in the top left corner is the percentage of battery charge remaining. If
proceeded by a ‘+‘, it means the battery is being charged.
3. The Record button saves data as a marked record in the USB memory stick, and also sends the
record to the host and WiFi ports. Data can also be recorded by pressing the recording switch on
the PLC leaf cuvette handle.
4. The percentage value in the top right corner is the estimated percentage of Auto-zero absorber
column capacity remaining based on the number of zeros performed since the last time the
counter was reset by the user (See Reset Zero Absorber on page 57).
5. The ‘Z’ button is used to initiate a manual zero.
6. A status or error message can be displayed in the Status Area.
Parameters in Parenthesis
Any parameter (i.e. Flow) that has a parenthesis is an active button that gives a direct link to a user
adjustable setting that can be changed. On completion of the setting, it returns to the measurement
screen from where it started. These are called Direct Link Settings
.
