• General set of service and repair tools.
• US and Metric Hex Key set • Standard straight slot tip screw drive set
• US and Metric socket set • Philips tip screw driver set
• Us and Metric wrench set • US & metric Allen wrench set
• Cutters • 7/16” Allen key, socket mounted
• Rubber mallet • Pliers
• Tape measure /Straight edge ruller • Inner and outer snap ring pliers
• DVM meter • Torque Wrenches: 9 in lbs to 100 in - lbs (83
ft-lbs)
• AC Clamp-on averageing current meter • DVM Multimeter
• Belt tension gauge – OTC Tools Model #:
6673
• Drive Belt tension Gauge (Kent-Moore BT-
33-73-F
• 2 Running belt tension gauges (Precor PN:
PPP000000020007101)
• Polar HRM simulator transmitter (Precor
PN: • PPP000000020045101)
• 12 " wonder bar • ESD safe vacuum cleaner
• ESD wrist strap
Supplies
• Super Lube Gel with Telfon by Permatex • Cleaning rags
• Mobil 1, NLGI 2 Teflon Synthetic Grease • Cleaner Degreaser (Simple Green)
• Loctite 243 Blue Medium Strength Thread-
locker
• Cable ties (1- 3/4", 3", 4" lengths)
Specification Summary Table
This table provides a summary of system component torque and belt rating specifications.
System Component Specification
RF coax connector 2.4 in-lbs (0.271 Nm)
Display mounting fasteners 180 in-lbs (20 Nm
Set screws 300 in-lbs (34 Nm)
Plastite screw fasteners 20 in-lbs (2.3 Nm)
Flathead screws 25 in-lbs (2.8 Nm)
Drive Belt Tension New Belt 100-120 lbs (45-54 kgs)
Drive Belt Tension Used Belt 80-90 lbs (36-41 kgs)
Drive Motor fasteners 204 in-lbs (17 ft-lbs, 23 N-m)
Experience Series 700 Line Treadmills
6
1 Introduction
General Information
