Motor Controller (MC) Replacement
About
This procedure provides instruction to replace the Motor Controller (MC
1
).
The Motor Controller (MC), is located in the Drive Motor compartment at the front of the tread-
mill under the hood cover.
ID Description
Motor Controller (MC)
Lift Motor
Drive Motor
Line Filter
Power Entry Assy Module
1
Motor Controller Module
Experience Series 700 Line Treadmills
84
5 Replacement Procedures
Motor Controller (MC) Replacement
