Precor TRM700-16 Base - P62, P80, and P82 Series Consoles

DIAGNOSTIC
TEST
TEST DESCRIPTION
• SEC - UP/DWN command response delay between the UPCA
1
and
LPCA
2
.
• Glitches - Momentary failures in the A/D potentiometer output. If there are
more than 50 Glitches, the lift motor should be replaced.
.
STOP KEY TEST
Menu path: MACHINE TEST > STOP KEY TEST
(P10, P30 consoles only)
Verifies the Stop Key and E-Stop function
Test sequence steps;
1.StopKey test - Press the Stop Key
2.Lanyard ESTOP test- Pull the lanyard to trip the emergency stop function.
3.Exit test - Press the Stop button to reset and exit test.
P62, P80, and P82 Series Consoles
Menu path:Hardware Validation Tests (5,1,7,6,5,7,6,1) > System Settings > System
Tests.
On P62, P80, and P82 consoles, the diagnostic tests are located in the Hardware Validation
System Tests menu.
SYSTEM TESTS TEST DESCRIPTION
AUTO STOP
TEST
Menu path: MACHINE TEST > AUTO STOP TEST
Test parameters;
• Status - User detected on running belt (detected/not detected)
• Step Count - Average # of footplants. Footplant averaging delay reset with
each speed change.
BELT SPEED
TEST
Menu path: MACHINE TEST > BELT SPEED TEST
Tests belt operating condition in 0.1 speed increments
Test parameters:
• AMPS IN: Treadmill input Current.
• VOLTS IN: Treadmill input Voltage
• VBUSS: Treadmill internal buss Voltage
1
Upper PCA board
2
Lower PCA board
Experience Series 700 Line Treadmills
23
3 Standard Service Modes
Hardware Validation Service Mode (51765761)
