DIAGNOSTIC
TEST
TEST DESCRIPTION
group of LEDs and verify that all LEDs illuminate. Press Back to exit the
test.
KEYBOARD TEST
An illuminated LED map of the function keys will be shown. Press each indi-
vidual key and verify that the corresponding LED extinguishes. Press and
hold BACK to exit the test.
PVS KEY TEST
Not used, OEM test.
HEART RATE
Tests the unfiltered, filtered, and pulse heart rate. Grasp the grips to test the
hand held heart rate. Use a Polar heart rate simulator to test the wireless
heart rate. Press the BACK button to exit this test.
ACTIVE STATUS
LIGHT
The current ASL
1
status light state (blue. pulsing blue, yellow, & pulsing yel-
low).
AS LIGHT
BRIGHTNESS
Sets the ASL light brightness level and ON/OFF state:HIGH. MED, LOW,
and ON/OFF.
MC
2
LIGHT
Shows current state of MC LED-Hold Quick Start to reset.
BELT SPEED
TEST
Menu path: MACHINE TEST > BELT SPEED TEST
Tests belt operating condition in 0.1 speed increments
Test parameters:
• AMPS IN: Treadmill input Current.
• VOLTS IN: Treadmill input Voltage
• VBUSS: Treadmill internal buss Voltage
• AMPS MTR: Current supplied to the drive motor.
AUTO STOP TEST
Menu path: MACHINE TEST > AUTO STOP TEST
Test parameters;
• Status - User detected on running belt (detected/not detected)
• Step Count - Average # of footplants. Footplant averaging delay reset with
each speed change.
.
INCLINE TEST
Menu path: MACHINE TEST > INCLINE TEST
Test parameters;
• A/D - lift motor incline position potentiometer A/D number.
1
Active Status Light: Service and maintenance status light.
2
Motor Controller Module
Experience Series 700 Line Treadmills
22
3 Standard Service Modes
Hardware Validation Service Mode (51765761)
