solution.
l General: 1 oz mild soap (Simple Green) to 30 oz. water.
l Console and PVS: a diluted solution of one part 91% Isopropyl alcohol to one part
water.
CAUTION: Do not use acidic cleaners and do not spray directly onto the equipment
surfaces.
Power, RF, and Ethernet Requirements
The following information provides the treadmill and console power, RF, and ethernet require-
ments to correctly and safely power and use the treadmill.
US and Canada power requirements
Precor treadmills must be connected to a 20 amp, individual branch circuit that can be shared
only with one PVS (Personal Viewing System) display. If you need additional help with the
power connections contact your Precor authorized dealer.
Individual branch circuit: An individual branch circuit provides a hot conductor and neutral
conductor to a receptacle. The conductors must not be looped, "daisy-chained", or connected
to any other conductors or receptacles. The circuit must be grounded according to NEC
guidelines or local region electric codes.
CAUTION:īNEC (National Electric Code) guidelines or local region electric codes
must be complied with.
Input Power
Nominal 120 VAC models
l Operating voltage: 90 VAC to 132 VAC.
l Frequency: 47 65 Hz
Nominal 240 AC Models
l Rated Operating voltage: 180 VAC - 264 VAC.
NOTE: An Internal operating voltage range of 180 ā 275 VAC with reduced per-
formance is allowed.
l Frequency: 47-65 Hz
Frame Ground
For operator safety and to minimize electrostatic discharge conditions the AC frame ground
continuity must also be verified to be a low resistance connection to the AC distribution ground
bar.
Experience Series 700 Line Treadmills
9
