8Theory of Operation
What's New
The TRM700-16 features and differences from previous generation TRMs including:
l Updated self lubricating running belt with no wax deck
l No Dynamic Brake Resister (DBR
1
)
l Redesigned dash and arms
l Service/maintenance Active Status Light (ASL
2
)
l Supports the P30, P62, and P82 consoles
l TRM700-16 and TRM800-14 use common base platform
l Ground Effects Impact Control System (GFX
3
®
)
l Integrated Footplant Technology (IFT
4
™)
Operating System Summary Information
Console - Upper PCA board (UPCA)
The console provides the user interface operational control inputs, the metric indicator inform-
ation, and the console-to-base communication interface. The console Upper PCA board
(UPCA
5
) sends the input control commands to the base Lower PCA board (LPCA
6
). The con-
sole also receives error code data from the base which is used to maintain the Error Log ser-
vice menu. The console also controls and sends the ASL
7
status state (based on the received
error codes) to the base.
The LPCA makes use of two main processors: the Master (also referred to interchangeably as
“Major”) and Slave (also as “Minor”).
1
Dynamic Brake Resistor The dynamic brake resistor dissipates power generated from the
main motor.
2
Active Status Light: Service and maintenance status light.
3
Ground Effects Impact Control Systtem: Patented treadmill design that out performs a nat-
ural running surface, absorbs high-impact movement, reduces joint stress and minimizes
fatique, and supports a solid adn controlled push off.
4
Integrated Footplant Technology: IFT recognize this change in speed when your foot strikes
the belt and adjust to match every stride, resulting in a smooth, fluid feel that enhances the
workout experience.
5
Upper PCA board
6
Lower PCA board
7
Active Status Light: Service and maintenance status light.
Experience Series 700 Line Treadmills
159
