SYSTEM TESTS TEST DESCRIPTION
• AMPS MTR: Current supplied to the drive motor.
INCLINE TEST
Menu path: MACHINE TEST > INCLINE TEST
Test parameters;
• A/D - lift motor incline position potentiometer A/D number.
• SEC - UP/DWN command response delay between the UPCA and LPCA.
• Glitches - Momentary failures in the A/D potentiometer output. If there are
more than 50 Glitches, the lift motor should be replaced.
USB
1
Test
List the active USB ports.
Touchscreen
Test
Verify touchscreen operation.
Touchscreen Cal-
ibration
Calibrates touchscreen finger press operation.
Backlight Test
Tests the display backlight performance.
RGB Test
Tests the display color performance.
Numeric Backlight
Test
Tests the LED numeric display backlight brightness level.
Numeric Display
Test
Tests the LED numeric display.
Heart Rate Tests the handlebar unfiltered, filtered, and pulse heart rate. Grasp the grips to
test the hand held heart rate. Use a Polar heart rate simulator to test the wire-
less heart rate. Press the back button to exit this test.
Club Settings Service mode (5651565)
Service Access Code: 5,6,5,1,5,6,5 (see "Service Access Codes" on page17)
Club Settings is used to manage and customize user defined workout limit parameters. On
touchscreen consoles, information about the machine HW/SW and error event code data is
included.
P10 & P30 Series Consoles
The Club Settings service software mode is used to configure and customize workouts.
Menu path: Club Settings (5,1,7,6,5,7,6,1) > DIAGS - CLUB SETTINGS
1
Short for Universal Serial Bus, is an industry standard developed in the mid-1990s that
defines the cables, connectors and communications profocols used in a bus for connection,
communication, and power supply between computers and electronic devices.
Experience Series 700 Line Treadmills
24
3 Standard Service Modes
Club Settings Service mode (5651565)
