The copying process is done with an add-on instruction (AOI) of the control software:
A
B
Fig. 13.3: Copy command in the contact plan logic routine
The entire copy instructions can be found in chapter21.5 „Add-On Instruction of the RSLogix 5000 Control
Software“ on page97. The call up is displayed in Fig. 13.4 on page62.
Fig. 13.4: Call up of the add on instruction “PMMDataCopy”
