Pulsar ULTRA 5 User Manual

Page 103
The Quick Setup Menu detailing the questions you will be asked, when setting up
your Flow 5, via the Quick Setup is shown below.
Quick Setup Menu
PMD Type
0 = Off (No Calculation)
1 = Exponential
2 = BS3680 Flumes
3 = BS3680 Weirs
4 = Not Available
5 = Special
6 = Universal
For Each Alarm
1 = Set to Relay 1
2 = Set to Relay 2
3 = Set to Relay 3
4 = Set to Relay 4
5 = Set to Relay 5
Exponential
1 = Supp. Rect.
2 = Trapezoid
3 = Venturi 4 =
Parshall
5 = Leopold L.
6 = V-Notch
7 = Other
8 = Contracted Rect
BS3680 Flumes
1 = Rectangular
2 = Rect. + Hump
3 = U-Throat
4 = U-Throat + Hump
BS3680 Weirs
1 = Rectangular
2 = V-Notch 90
o
(Full 90
o
)
3 = V-Notch 53
o
8’ (Half 90
o
)
4 = V-Notch 28
o
4’ (Qtr 90
o
)
5 = Broad Crested
Special
1 = Palmer Bowlus
2 = H-Flume
3 = V-Notch Angle
Calculation
1 = Absolute
2 = Ratiometric
How Many Alarms
0 = No Alarms
1 = One Alarm
2 = Two Alarms
3 = Three Alarms
4 = Four Alarms
5 = Five Alarms
For Each Alarm
1 = High Alarm
2 = Low Alarm
3 = Hi Hi Alarm
4 = Lo Lo Alarm
5 = Loss of Echo
Quick Setup
Universal
1 = Linear flow
2 = Non-Linear flow
Area Velocity
(Optional)
1 = Circ. Straight
2 = Rectangular
3 = Trapezoid
4 = Round Pipe
7 = Other
Optional
3 = Linear A/V
4 = Non-Linear A/V
