Page 11
Chapter 2 Installation
Power Supply Requirements
Ultra 5 can operate from AC supply or from a DC battery. The AC is either
105-120V 50/60Hz or 170-240V 50/60Hz, depending on the position of the
selector switch. The DC is 18-36V. In all cases the Ultra 5 will typically
consume 6W of power, with a maximum of 10W.
Location
All electronic products are susceptible to electrostatic
shock, so follow proper grounding procedures during
installation.
Ultra 5 must be mounted in a non-hazardous (safe) area, and the transducer
fitted in the hazardous area.
