Page 5
Product Specification
Physical
Wall Mount
Outside dimensions 235 x 184 x 120 mm
Weight Nominal 1 kg
Enclosure material/description Polycarbonate, flame resistant to UL91
Cable entry detail 10 cable entry knock outs, 5 x M20, 1 x M16
underside,
4 x PG11 (18mm) at rear
Fascia Mount
Outside dimensions 200 x 112 x 108
Weight Nominal 1.3kg
Enclosure material/description Stainless Steel back, Polycarbonate UL94-
V0 front and bezel
Rack mount 10HP x 160 mm deep x 3U (128.5 mm) high
Enclosure material/description Aluminium frame
Panel mount 72 mm wide x 144 mm high x 176 deep
Enclosure material/description ABS (Acrylonitrile Butadiene Styrene)
Transducer cable extensions 2-core screened
Maximum separation 1000 m
Environmental
IP Rating (Wall) IP65
IP Rating (Fascia) IP64
Optional IP rated panel mount IP65
Max. & min. temperature (electronics) -20 ºC to +50 ºC
Flammable atmosphere approval Safe area: compatible with approved dB
transducers (see transducer spec' sheet)
CE approval See EU Declaration of conformity
Performance
Accuracy 0.25% of the measured range or
6 mm (whichever is greater)
Resolution 0.1% of the measured range or 2 mm
(whichever is greater)
Max. range Dependant on application and transducer
(maximum 40m dB40)
Min. range Dependent upon application and transducer
(minimum zero dB Mach3)
Rate response fully adjustable
Echo Processing
Description DATEM (Digital Adaptive Tracking of Echo
Movement)
Outputs
Analogue output Isolated (floating) output (to 150V) of 4-20
mA or 0-20 mA into 500
