Pulsar ULTRA 5 User Manual

Page 207
mA Output Parameters
Range
P830 mA Range
This parameter determines the range of the mA output, from the following.
Option
Description
0= Off
mA output disabled.
1= 0 to 20 mA
mA output directly proportional to the mA mode
(P831), so if the reading is 0% the output is 0 mA. If
the reading is 100% the output is 20 mA.
2= 4 to 20 mA
(Default)
mA output directly proportional to the mA mode
(P831), so if the reading is 0% the output is 4 mA. If
the reading is 100% the output is 20 mA.
3= 20 to 0 mA
mA output inversely proportional to the mA mode
(P831), so if the reading is 0% the output is 20 mA. If
the reading is 100% the output is 0 mA.
4= 20 to 4 mA
mA output inversely proportional to the mA mode
(P831), so if the reading is 0% the output is 20 mA. If
the reading is 100% the output is 4 mA.
Operation
P831 mA Mode
This parameter determines how the ma Output relates to what is measured.
By default, it operates exactly the same as the display (P100), but it can be
set to operate as follows:
Option
Description
0 = Default
mA output relative to Mode P100
1 = Distance
mA output relative to distance.
2 = Level
mA output relative to level.
3 = Space
mA output is relative to space.
When Ultra Wizard = 1 Level/Volume
4 = Avg. Level
mA output is relative to the average level of
two points of measurement. P100 = 4
5 = Volume
mA output is relative to volume P100 = 5
6 = Vol. (Avg).
mA output is relative to the average volume
of two points of measurement P100 = 6
