Pulsar ULTRA 5 - Dimensions

Page 146
P103 Input 2 (Optional)
The 4-20 mA input is available as an option (Consult Pulsar for details of
availability), and can be used to replace the transducer for applications
where an ultrasonic transducer cannot be used.
Use this parameter to set the second input device when using in Average or
Differential Mode, and P101 Transducer = 1 (Optional Auxiliary Input).
Option
Description
0= None (Default)
Second Transducer input not required.
1 = dB3
Transducer is a dB3. Range 0.125 to 3.00 metres
2 = dB6
Transducer is a dB6. Range 0.3 to 6.00 metres
3= dB10
Transducer is a dB10. Range 0.3 to 10.00 metres
4= dB15
Transducer is a dB15. Range 0.5 to 15.00 metres
5= dB25
Transducer is a dB25. Range 0.6 to 25.00 metres
6 = dB40
Transducer is a dB40. Range 1.2 to 40.00 metres
7 = dBS6
Transducer is a dBS6. Range 0.2 to 6.00 metres
8 = dBMach3
Transducer is a dBMach3 Range 0.0 to 2.425 mtrs.
Dimensions
P104 Measurement Units
This parameter sets the units you want to use for programming and display
Option
Description
1 = metres (Default)
All units of measure are METRES
2 = cm
All units of measure are CENTIMETRES
3 = mm
All units of measure are MILLIMETRES
4 = feet
All units of measure are FEET
5 = inches
All units of measure are INCHES
P105 Empty Level
This parameter is to be set to the maximum distance from the face of the
transducer to the empty point, in P104 Measurement Units. Note this
value affects span as well, (see important information below), so should be
set before span.
Important Information
When using the dB Mach 3 the empty distance is measured from the end
of the horn to the empty point in P104 Measurement Units.
