Pulsar ULTRA 5 User Manual

Page 194
Dimensions
P710 Dimension A
This parameter is used to enter dimension “A” of the Primary Measuring
Device, where applicable, see table below for further details.
P711 Dimension B
This parameter is used to enter to enter dimension “B” of the Primary
Measuring Device, where applicable, see table below for further details.
P712 Dimension C
This parameter is used to enter to enter dimension “C” of the Primary
Measuring Device, where applicable, see table below for further details.
P713 Dimension D
This parameter is used to enter to enter dimension “D” of the Primary
Measuring Device, where applicable, see table below for further details.
Primary Measuring Device
P710
Dim “A”
P711
Dim “B”
P712
Dim “C”
P713
Dim “D”
P700 = 1 Exponent
P701 = 1 Supp. Rectangular Weir
P702 = 1 Absolute
Crest
Width
Not
Required
Not
Required
Not
Required
P700 = 1 Exponent
P701 = 2 Trapezoidal Weir
P702 = 1 Absolute
Crest
Width
Not
Required
Not
Required
Not
Required
P700 = 1 Exponent
P701 = 5 Leopold Lagco Flume
P702 = 1 Absolute
Throat
Diameter
Not
Required
Not
Required
Not
Required
P700 = 1 Exponent
P701 = 6 V Notch
P702 = 1 Absolute
V Notch
Angle
Not
Required
Not
Required
Not
Required
P700 = 2 BS 3680 Flume
P701 = 1 Rectangular
Approach
Width
Throat
Width
Throat
Length
Not
Required
P700 = 2 BS 3680 Flume
P701 = 2 Rectangular with hump
Approach
Width
Throat
Width
Throat
Length
Hump
Height
P700 = 2 BS 3680 Flume
P701 = 3 U-Throated
Approach
Width
Throat
Diameter
Throat
Length
Not
Required
P700 = 2 BS 3680 Flume
P701 = 3 U-Throated with hump
Approach
Width
Throat
Diameter
Throat
Length
Hump
Height
P700 = 3 BS 3680 Weir
P701 = 1 Rectangular
Approach
Width
Crest
Width
Crest
Height
Not
Required
P700 = 4 Area Velocity
P701 = 1 Circular Straight
Base
Diameter
Not
Required
Not
Required
Not
Required
