Page 208

Option

Description

When Ultra Wizard = 2 Pump/Differential

4 = Avg. Level

mA output is relative to the average level of

two points of measurement. P100 = 4

5 = Differential

mA output is relative to the differential

between two points of measurement P100 = 5

When Ultra Wizard = 3 Flow

4 = OCM Head

mA output is relative to OCM head.

5 = OCM Flow

mA output is relative to OCM flow.

6 = Average Flow

mA output is relative to average flow

Setpoint

By default, the mA Output will represent the empty (0 or 4mA dependant

on (P830) mA Range) and 100% of the operational span (20mA), but you

may wish to have the output represent a section of the operational span. For

example, the application has an operational span of 6 metres but output is to

represent empty (0 or 4mA dependant on (P830) mA Range) to a level of

5 metres (20mA). If so P834 (Low Level) should be set to 0.00 metres and

P835 (High Level) should be set to 5 metres.

P834 mA Low Level

This parameter sets the level, distance or space, depending on the selected

mA Out Mode (P831) at which the low mA output will occur (0 or 4mA

dependant on (P830) mA Range)

Default = 0.000m

P835 mA High Level

This parameter sets the level, distance or space, depending on the selected

mA Out Mode (P831) at which the high mA output will occur (20mA).

Default = 6.000m

Limits

P836 mA Low Limit

This parameter sets the lowest level that the mA output will drop to, the

default is 0mA, but you can override this if the device you connect to cannot

for example accept less than 2mA, yet you want to use the 0-20mA range.

Default = 0.00mA
