Page 42
Pump/Diff
If you require to set up a pump or differential application, then press “2”
followed by “ENTER” the message “Loading ***” will be displayed and
your Ultra 5 will be configured as an Advanced 5. Confirmation that
configuration has been completed will be given by the unit type, software
version and serial number being displayed briefly on the LCD and the unit
advancing to the relevant “Quick Setup” menu.
For full details on how to programme the Advanced 5, using the Quick
Setup Menu, please proceed to Chapter 6 Pump/Differential. For a full
description of all features and parameters please refer to Chapter 8
Parameter Listing and Description.
Advanced 5
The Advanced 5 level controller provides sophisticated pump control with a
complete range of pump “duties” being available and advanced control
routines for use with differential and level control, for an extremely wide
variety of applications.
The Advanced 5 can measure from 0.12m to 40m from the face of the
transducer to the surface being monitored, dependent on the transducer used.
The Advanced 5 can show level, space, distance or the average or
differential between two points of measurement, on the display.
The five user definable relays with individual setpoints can be programmed
to activate alarms, pump starters, or other control equipment.
The 4-20 mA output is fully programmable to provide an output relative to
level, distance, average or differential. The optional mA Input can be used
to connect devices such as pressure transducers so that the sophisticated
control routines of the Advanced 5 can be used in applications where
ultrasonic transducer are unable to operate.
Flow
If you require to set up a flow application, then press “3” followed by
“ENTER” the message “Loading ***” will be displayed and your Ultra 5
will be configured as a Flow 5. Confirmation that configuration has been
completed will be given by the unit type, software version and serial number
being displayed briefly on the LCD and the unit advancing to the relevant
“Quick Setup” menu.
For full details on how to programme the Flow 5, using the Quick Setup
Menu, please proceed to Chapter 7 Flow. For a full description of all
features and parameters please refer to Chapter 8 Parameter Listing and
Description.
