Pulsar ULTRA 5 User Manual

Page 152
Alarms
P210, 220, 230, 240, 250 =1 (Alarm)
The second parameter for each relay determines the function of the alarm.
P211, P221, P231. P241, P251 - Relay Function
This parameter defines what function the alarm will respond to as follows.
Option
Description
0= Off (Default)
Relay will not operate.
1= Level
Alarm is based on the level in the vessel, and the
type of level alarm (P212, 222, 232, 242, 252) and
two setpoints must be set (P213, 223, 233, 243,
253 & P214, 224, 234, 244, 254). Setpoints are
entered in Display Units or % of span as referenced
to Empty Level
*
.
2= Rate of Change
Alarm is based on the rate of change of level in the
vessel, and the type of rate of change alarm (P212,
222, 232, 242, 252) and two setpoints must be set
(P213, 223, 233, 243, 253 & P214, 224, 234, 244,
254). Setpoints are entered in Display Units per
minute or % of span per minute and a negative
value should be entered for a Rate Alarm on a de-
creasing level, and a positive value for an
increasing level.
3= Temperature
Alarm is based on the temperature, and the type of
temperature alarm (P212, 222, 232, 242, 252) and
two setpoints must be set (P213, 223, 233, 243,
253 & P214, 224, 234, 244, 254). The temperature
used depends on the temperature source selected
(P852). Setpoints are entered in
o
C.
4= Loss of Echo
Alarm is raised if the Failsafe Timer (P809)
expires. No setpoints are required.
5= Loss of Clock
Alarm is raised if the real time clock fails. No
setpoints are required.
When Ultra Wizard =2 Pump Differential
and Pump Efficiency Enabled
6= Pump Efficiency
When Pump Efficiency is enabled, Alarm is
based on the Efficiency of the pump which is
allocated to the relay I.D. (P212, 222, 232, 242,
252) and two setpoints must be set (P213, 223,
233, 243, 253 & P214, 224, 234, 244, 254).
Setpoints are entered in %.
