Page 153
14= Service Alarm
(Only available in
firmware version
7.4.3 and greater)
Alarm is raised when the service alarm date/time
interval expires. This is set in ‘System > Service
Alarm > Date (P194) > Interval (P195)’. The
alarm trigger is automatic in the unit and is set at
12 noon, meaning that the alarm will activate at
12 noon on the date programmed into the unit
when the service is now due.
No setpoints are required.
Note that the loss of echo and loss of clock will also be shown on the
display as “LOST ECHO” and “LOST CLOCK” respectively.
The third parameter for each relay determines the alarm ID for the relay
you wish to set.
P212, P222, P232, P242, P252 - Relay Alarm ID
When P211, 221, 231, 241, 251 = 4 (Loss of Echo) or 5 (Loss of Clock)
This parameter has no function and will not be displayed
When P211, 221, 231, 241 251 = 1 (Level), 2 (Rate of Change) or 3
(Temp.)
This parameter defines which alarm type, or identification, the relay
should respond to, as follows.
Alarm ID
Description
Setpoints
1=General (Default)
Relay goes “ON” when
the value reaches the ON
setpoint and goes “OFF”
when the value reaches
the OFF setpoint.
P213, 223, 233,
243, 254 is ON
Setpoint; P214,
224, 234, 244, 254
is OFF Setpoint
2= High
Relay goes “ON” when
the value rises to the ON
setpoint and goes “OFF”
when the value lowers to
the OFF setpoint.
ON> OFF
Relay Setpoints
P213, 223, 233,
243, 253 and P214,
224, 234, 244, 254
Setpoints, can be
set in any order as
the unit ‘knows’
that you are setting
a high-level alarm.
3= Hi-Hi
Same as 2 = High, but
different identifier.
