Bargraph
P829 Bargraph
By default, the bar graph will be representative of the reading obtained, as
determined by the Mode P100. When P100 = 4 (Average) or 5
(Differential) the bar graph can be assigned to be representative of the level
on any of the two points of measurement. This parameter is automatically
set to the correct default option when selecting the Mode P100 and Xducer
(P101), and under normal circumstances will not require changing.
The options, dependant on the value entered for Mode P100, are as follows:
Option
Description
When Ultra Wizard = 1 Level/Volume or 2 Pump/Differential
1 = Auxiliary (Optional)
Bargraph will be representative of levels
obtained from optional Aux. Input.
2 = Xducer 1 (Default)
Bargraph will be representative of levels
obtained from Xducer 1.
3 = Xducer 2
Bargraph will be representative of levels
obtained from Xducer 2.
4 = Avg. Level or Diff.
Bargraph will be representative of the
Avg/Diff Level of two points of
measurement, as selected in Mode P100.
When Ultra Wizard = 1 Level/Volume
5 = Volume
Bargraph will be representative of the
volume, as selected in Mode P100.
6 = Vol. (Avg.)
Bargraph will be representative of the
Average Volume of two points of
measurement, as selected in Mode P100.
When Ultra Wizard = 3 Flow
1 = Level
Bargraph will be representative of level.
2 = Head (Default)
Bargraph will be representative of head.
3 = Flow
Bargraph will be representative of flow.
