Page 40
Chapter 4 Ultra Wizard
The Ultra Wizard menu allows you to turn Ultra 5 into anyone of three
dedicated ultrasonic devices to exactly suit the requirements of your
application.
Ultra Wizard Menu
To access the Ultra Wizard, you need to go from Run Mode to Program
Mode.
Enter Program Mode
First you need to go from run mode into program mode. Assuming the
passcode is the default 1997, then you should enter this.
Choose Ultra Wizard
Now you need to go into the Ultra Wizard. You will see on the menu the
words ‘Ultra Wizard’, which is the first item on the menu, select and press
This takes you to the “Select Application Menu”
and provides the choice of:
1 = Level or Volume measurement (Lev/Vol
2 = Pump Control or Differential measurement and control (Pump/Diff)
3 = Open channel Flow measurement (Flow)
Once you have selected the application of your choice the Ultra 5 will be
configured to the unit type specific to that task as follows:
