Page 6
Digital output Full Duplex RS232
Volt free contacts, number and rating 5 form "C" (SPDT) rated at 5A at 240V AC
Display 6 digits plus 12-character text, plus bar
graph with direction indicators, remote
communicator identifier, and
program/run/test mode indicators
Analogue Input
Available as an Option
0-20 or 4-20 mA Isolated (floating) input (to 150V) 4-
20mA or 0-20 mA source, open circuit
voltage 33V, 22V at 4mA, 14V at 20mA
(user programmable and adjustable) 0.1%
resolution
Programming
On-board programming By integral keypad
PC programming via RS232
Remote programming
(Rack and Panel option only) By optional infra-red communicator
Programming security Via passcode (user selectable and
adjustable)
Programmed data integrity Via non-volatile RAM, plus backup
Supply
Power supply 115V ac + 5% / -10% 50/60 Hz,
230V ac + 5% / -10% 50/60 Hz,
dc 18 - 36V
10W maximum power (typically 6W)
Fuses 100 mA at 170-240 VAC (fitted as standard)
200 mA at 85-120 VAC
Remote Communicator
Batteries 2 x AA alkaline batteries. Do not use
NiCad’s.
Pulsar Process Measurement Limited operates a policy of constant development and
improvement and reserve the right to amend technical details as necessary.
